Hello, in this detailed guide i will show you how to add Fortigate to GNS3, how to do basic network configuration for the machines, and how to access FortiGate through CLI (Command-Line) and web.
Requirements
------------------------------------------------------
• GNS3 (V 2.0.3) & GNS3 VM (Or above)
• Download FortiGate appliance from Here
• Download FortiGate 5.6 Image from Here
• Download Tiny Linux Firefox Appliance from Here
• Download Tiny Linux Firefox Image from Here
------------------------------------------------------
Kershaw trooper no serial number. Kershaw’s Trooper has proven itself for durability, functionality, and handsome looks. In addition, each Trooper is serial numbered. Made of AUS8A stainless steel with a 56-59 Rockwell hardness rating, the Trooper’s blade, pommel, and guard are polished to a mirror finish. A durable Phenolic handle adds to the knife’s strength and its rich ebony color enhances the Trooper’s good looks. The Trooper comes complete with a presentation case, engraving plate, and genuine leather boot clip sheath.
Import Appliances & Images
Start a new blank project, click File > Import Appliance, then choose the FortiGate appliance file (.gns3a)
Click Next, then choose 'Run the appliance on the GNS3 VM(recommended)' option, after GNS3 verify the VM requirements to run the appliance, click Next.
Click on Refresh, a list of all the required FortiGate files will appear like the following
In your case all the files will be missing. For this guide i will be using FortiGate 5.6.1.
Under FortiGate 5.6.1 on the list, click on FGT_VM64_KVM-v5-build1484..., then import, then choose the file extracted from the FortiGate Image.
Note: In order for FortiGate to operate, it needs an empty harddisk
The harddisk can be created using linux tool called 'qemu-img' using the following command:
or you can download the file from Here .
To import the harddisk into GNS click on empty30G.qcow2 under FortiGate 5.6.1 on the list, then import and choose the harddisk file.
After adding the two files they will be ready to install, click on Next, then choose /usr/bin/qemu-system-x86_64 (v2.5.0) for Qemu binary, then click Next, Next, Finish.
FortiGate will appear on Security Devices Tab
Ha Fortigate 5.4
To import Tiny Linux Firefox, Click File >>> Import Appliance >>> Choose the Tiny Linux Firefox Appliance file >>> Click Next >>> Under Firefox 31.1.1~2 click on linux-tinycore-linux-6.4... then import >>> choose the Tiny Linux Firefox image file >>> Click Next >>> choose /usr/bin/qemu-system-i386 (v2.5.0) for Qemu binary >>> Click Next, Next, Finish.
Firefox will appear in the End Devices tab.
Network Topology & Configuration
For this guide i will configure a very basic network topology.
Fortigate 5.4 Cookbook
FortiGate Configuration
Right-Click on FortiGate, then click on Console to access the CLI. The username is 'admin' and blank password.
To set IP on port 1 run the following commands.
Tiny Linux Firefox Configuration
Right-Click then choose console, a GUI will appear.
open a terminal and run 'ifconfig' to check for network interfaces. in my case i will configure interface 'eth0'. Run the following commands to set an IP.
To open Fortigate through web, click on Firefox and type your default gateway IP in the URL bar. Enter username 'admin' and empty password
Finally, the portal will open and you should see the following
I hope that this will help you in configuring FortiGate inside GNS3.
