Temperature Controller

Delta Temperature Controller User Manual 2007-09-17 - 4 - © DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED DTA DTB DTC.

Thank you very much for purchasing DELTA DTC1000/2000 Series Temperature Controller. Please read this

Manufacturer: Delta Electronics, Model: DTC1000 Series, Type of document: User manual, Category: Switch, Number of pages: 2. Mar 2, 2011 - DTC Delta temperature Controllers. DTC Instruction Manual. Hello sir, plz tell me how I can communicate multiple DTC 1000 modules.

instruction sheet before using your DTC1000/2000 series to ensure proper operation, and please keep this instruction
Caution
DTC1000/2000 series is an OPEN-TYPE device and therefore should be installed in an enclosure free of airborne
dust, humidity, electric shock and vibration. The enclosure should prevent non-maintenance staff from operating the
device (e.g. key or specific tools are required to open the enclosure) in case danger and damage on the device may
WARNING!
1. Prevent dust or metallic debris from falling into the controller that will cause malfunction. DO NOT modify or
disassemble the controller. DO NO use extra terminals.

Fargo Dtc 1000

2. Do not install and/or use the controller in places subject to:
high humidity and high radiation
3. Switch off the power when wiring or changing input sensors.
4. Be sure to use compensating wires that match the thermocouple types when extending or connecting the
5. Shorten the wire when wiring a platinum resistance thermometer (RTD) to the controller, and separate power cable
from load wires to prevent interference and conductive influence.
6. Make sure the power cable and signals device are installed correctly before switching on the power of
7. DO NOT touch the terminals or repair the controller when the power is on to prevent electric shock.
8. Wait at least one minute after the power is off to allow the capacitor to discharge. DO NOT touch any internal circuit
9. DO NOT touch the internal terminals no matter the power is on or off.
10. DO NOT place other heating source (e.g. power supply) in parallel with DTC1000/2000 during the installation.
Model Name Explanation
2
4
DTC: Delta C series temperature controller
1
2: Controller connected in parallel
2
1: 1 auxiliary output. Not available now.
2: 2 auxiliary outputs. Not available now.
3
Optional
02: EVENT input. Not available now.
V: Voltage pulse output 12V +10% ~ -20%
Main output type
L: Linear voltage output 0 ~ 10V
Enclosed functions: DC24V input, 2 outputs, relay output for output 2, RS-485 communication.
Power supply
Voltage range
Power consumption
Rated 24 VDC, Max. 24 W combined, 3W + 3W x number of DTC2000 controllers (Max. 7)
Input sensors
Linear DC input: 0 ~ 5V, 0 ~ 10V, 0 ~ 20mA, 4 ~ 20mA, 0 ~ 50mV
Analog input: 0.15 sec. Thermocouple or platinum RTD: 0.4 sec.
PID , programmable PID, Manual, ON/OFF
Voltage pulse: 12VDC, Max. output current: 40mA
Current: DC 4 ~ 20mA (Load resistance: < 500Ω)
Analog voltage: 0 ~ 10V (Load resistance: > 1,000Ω)
Output function
Proportional output is available only when output 1 is linear voltage/current output.
12 alarm modes
RS-485 digital communication, 2,400bps ~ 38,400bps
Communication protocol Modbus protocol, ASCII/RTU format
Internal terminals available to transmit 24V power supply and communication signals
Vibration resistance
for 10mins, each in X, Y and Z direction
Shock resistance
, 3 times in each 3 axes, 6 directions
Ambient temperature
C
Storage temperature
C
< 2,000m
35% ~ 85% RH (non-condensing)
2
4
1
3
1
2
Input
DTC1000/2000 series supports the following input sensors:
Manual
0 ~ 50mV linear voltage input
0 ~ 20mA linear current input
0 ~ 5V linear voltage input
Platinum RTD (Pt100)
Thermocouple TXK type
Thermocouple L type
Thermocouple S type
Thermocouple N type
Thermocouple T type
Thermocouple K type
Note 1: The current input is built-in with 249Ω precision resistor. See 'How To Set up Current Input' section.
The range of linear input and feedback value is adjustable. Range of input feedback: -999 ~ 9,999. Take 0 ~ 20mA input
as example, -999 refers to 0mA input, and 9,999 refers to 20mA input. If we change the range to 0 ~ 2,000, 0 will refer to
0mA input, and 2,000 will refer to 20mA input. 1 display scale = 0.01mA.
There are several output types available from DTC1000/2000 series: Control Output (heating/cooling), Alarm Output
Control Output
DTC1000/2000 series offers 2 outputs for heating or cooling control. If you require dual loop output, the 2 outputs
should be set to different actions (heating or cooling). If you require the 2 outputs are set to the same control action, only
the control cycle of output 1 will be valid, and the 2 outputs will act at the same time.
The control methods include: PID control, ON/OFF control, Manual control and programmable PID control.
DTC1000R/V/C/L
RUN/STOP switch
Wiring and Model name
3
4
7
5
8
6
10
Specification label
8
9
Extension clip
10
11
3.4
12
13
DTC2000R/V/C/L
Wiring and Model name
3
DIN rail clip
6
3
7
LED indicators
5
6
8
Extension port
8
9
10
3.4
Register Value
17
16
15
14
13
°
-200 ~ 600
°
-20 ~ 400
°
-200 ~ 800
°
-200 ~ 500
o
-200 ~ 850
°
100 ~ 1,800
°
0 ~ 1,700
°
0 ~ 1,700
°
-200 ~ 1,300
°
0 ~ 600
°
-200 ~ 400
°
-100 ~ 1,200
°
-200 ~ 1,300
Cooling hysteresis
ON
Cooling
Delta Dtc 1000 Manual
OFF
Set Point
Output
Cooling
PV
Figure 2: PID Control, Cooling) Control
Heating hysteresis
Heating
Deadband: Dead
Output
Cooling
0
Figure 5: PID control
The programmable PID control includes 8 patterns (Pattern 0 ~ 7). Each pattern contains 8 steps (Step 0 ~ 7) and
parameters: 'link pattern', 'cycle' and 'the number of steps'.
Start Pattern: The user can set up which pattern is the start pattern for the programmable control.
Steps: Includes the settings of the two parameters, set point X and execution time T, indicating that the set point (SV)
F)
has to rise to temperature X after the period of execution time T. If the result of the set point X is the same as that of
the previous setting, the process is called 'Soak'; otherwise, it is called 'Ramp'. Therefore, the programmable control
F)
is also known as Ramp/Soak control. The default setting of the first step is Soak control. The temperature will first rise
F)
to the set point X and remain at X. The total execution time is T.
F)
Link Pattern: The pattern to be executed following the current pattern. If the setting is not 0 ~ 7, the set point will
F)
°
Cycle: The additional number of cycles for a pattern. For example, if the parameter is set to 2, it refers to the pattern
F)
has to execute additional twice, totaling the execution to 3 times including the original one.
F)
The Number of Steps: The number of steps in each pattern (range: 0 ~ 7). For example, if the parameter is set to 2,
F)
it refers to the pattern will execute Step 0 ~ Step 2, and other steps will not be executed.
F)
F)
The Execution: Available settings include 'run', 'program hold', 'program stop' or 'stop'.
F)
1. When this parameter is set to 'run', the program will start its execution from step 0 of the start pattern.
2. When this parameter is set to 'program hold', the program will stop and the temperature will stop at the SV before
the program stops. If the user sets to 'run' again, the program will resume the step before the program stops and
3. When this parameter is set to 'program stop', the program will stop and the temperature will stop at the SV before
the program stops. If the user sets to 'run' again, the program will execute again from Step 0 of the start pattern.
4. When this parameter is set to 'stop', the program will stop, and the control output will be disabled.
If Output 1 of this DTC1000/2000 series is linear voltage or current, the user can set it to 'Proportional Output'.
Proportional output refers to the output varies with the input. For example, if the input range is set to 0 ~ 1,000, and
when the input value is 0, the output will be 0mA or 0V. When the input value is 1,000, the output will be 20mA or 10V.
10V or 20mA
output slope
PV Low
Alarm Output
DTC1000/2000 series offers 12 alarm modes. When the PV exceeds or falls below SV, the alarm output will be enabled.
Mode
0
Alarm output will be enabled when the temperature reaches upper and lower
1
Alarm will be enabled when the PV exceeds SV + AL-H or falls below SV –
Output
Heating
PV
Figure 3: PID Control, Heating Control
Cooling hysteresis
PV
Figure 4: ON/OFF Control
Bandwidth: Negative
Cooling
PV
Set Point
Output
10V or 20mA
PV
PV Low
Figure 7: Proportional Output
1000
OFF
OFF
SV
